FRAME
MAX technology carbon, disc, BB86, 142x12 mm thru axle, R.A.T Evo technology, Di2/mechanical, flat mount 160 mm, internal cable routing
FORK
Carbon, disc, 100x12 mm R.A.T thru axle, R.A.T Evo Technology, flat mount 160/160 mm, internal cable routing
SHIFTER
Shimano Ultegra R8020
FRONT DERAILLEUR
Shimano Ultegra R8000
REAR DERAILLEUR
Shimano Ultegra R8000
SPROCKET
Shimano Ultegra R8000
CRANKSET
Shimano Ultegra R8000
BOTTOM BRACKET
Shimano Pressfit Road BB86
TRANSMISSION OF DRIVE
front: 52/36, rear: 11-30
HANDLEBAR
BBB Deluxe, aluminium, drop: 125mm, reach: 70mm
STEM
BBB Rider BHS-109 Deluxe, 31.8mm, 7°
HEADSET
ACROS, IS 52/40-IS52/42
SEATPOST
FOCUS Aero Carbon, D-shape, 350mm, set-back: 15mm
BRAKES
Shimano Ultegra R8020
BRAKE LEVER
Shimano Ultegra R8020
WHEELSET
Novatec R5, carbon, 20-622, front: 12x100 mm, rear: 12x142 mm, height: 50 mm
TIRES
Vittoria Rubino TLR, 700 x 25C, Folding
BIKE WEIGHT INCL. BATTERY IN KG.
8,10 kg
SIZE
47,50,52,54,56,58,61
* Subject to technical modification without notice. Errors and omissions excepted.
